Model
SFP 1.25G LX

Item specifics

Data Rate
1.25Gb/s
Wavelength
1310nm&1550nm
Connector
Duplex LC
Distance
10~120km
Fiber Type
Single-mode Fiber
Temperature
0°C-70°C

Review

Description

Description

1.25G LX Duplex LC SFP Transceiver Module

SFP-1.25G-LX Small Form Factor Pluggable (SFP) Transceiver is a high performance, cost effective module which has a Duplex LC optics interface, Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses 1310nm&1550 nm VCSEL laser, up to 8dB link budge ensure this module 1000BASE Ethernet 10~120km application.

Technical Data
ITEM
Technical Parameters
Data Rate
1.25Gb/s
Wavelength
1310nm&1550nm
Connector
Duplex LC
Distance
10~120km
Fiber Type
Single-mode Fiber
DDM
YES
Temperature
0°C-70°C
Chip
Taiwan icreate
Products Features
* Low power consumption, Stable signal transmission
* Nano thickened gold-plated contact, Plug and play, ensure repeated insertion and withdrawal, stable contact, prevent poor contact, and improve the life of electric shock wear
* High quality laser, Low jitter, High sensitivity, Low attenuation, High performance
* High Quality Stainless Steel Housing, High-quality SUS304 stainless steel housing, environmental protection, strong and sturdy;Abrasion resistance, high temperature resistance, corrosion resistance, good heat dissipation effect.
Application
* Gigabit Ethernet
* Fiber Channel
